SPL-580020
SPL-580020
WLAN 2.4 GHz. Panel Antenna is light weight weather proof. The antenna is supplied with complete mounting kit suitable for choosing any direction for radiation. The antenna maintai...
Model
SPL-580020
Frequency
5150-5850 MHz
Gain
20 dBi. Gain
WLAN 2.4 GHz. Panel Antenna is light weight weather proof. The antenna is supplied with complete mounting kit suitable for choosing any direction for radiation. The antenna maintains consistent fault free working over years of use.
Our standard guarantee terms for one year for free replacement/repair makes it an ideal choice.
Dimension = 305 x 305 x 25 mm
Technical Specifications
SPL-580020
| ELECTRICAL DATA | |
|---|---|
| Frequency Range (MHz) | 5150-5850 |
| Gain (dBi) | 20 dBi. |
| Bandwidth (MHz) | 700 |
| Polarization | Vertical |
| Input Impedance (Ohms) | 50 |
| Beamwidth 3db (Degrees) | 20° |
| Beamwidth Hpp (Degrees) | 30° |
| Front to Back Ratio | 27 dB. |
| VSWR | 1:1.5 or Better |
| RF Power Handling Capacity (Watts) | 100 |
| Input Termination | N-Female |
| Lightning Protection | DC Ground |
| MECHANICAL DATA | |
|---|---|
| Materials | Aluminum |
| Mounting HW | Stainless Steel |
| Weight (Kgs) | 1.2 |
| Wind Rating (KMPH) | 140 |
| Operating Temperature | -40℃~+65℃ |
Disclaimer
1. All features, functionality and product specifications are subject to change without prior notice
2. Customized in-band and out-of-band versions are available on request
